    Metal Cut 1325 Plate And Tube Integrated Plasma Portable Cnc Plasma Cutter

    Ask Lasest Price
    Brand Name : Honest
    Model Number : HN1325
    Certification : CE ISO
    Price : $5000 / Set~$8000 / Set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10 Set / Month
    Delivery Time : After 15-30 Days
    • Product Details
    • Company Profile

    Metal Cut 1325 Plate And Tube Integrated Plasma Portable Cnc Plasma Cutter

    Metal Cut 1325 Plate And Tube Integrated Plasma Portable Cnc Plasma Cutter

    Hot Sales Metal Cut 1325 Cnc Plasma Cutting Machine Steel Substrate

    Machine overview


    We do this line many years ,have rich experience and professional knowledge ,will let you get the most suitable machine with the right configuration . This ability can let you avoid many mistake and avoid some trouble .Other factory usually lack this experience ,and bring some trouble for the real customer .


    ① We do this line many years, have rich experience and professional knowledge, will let you get the most suitable machine with the right configuration. This ability can let you avoid many mistake and avoid some trouble. Other factory usually lack this experience, and bring some trouble for the real customer.


    ② If use the plasma cutting machine to cut the the thick meal, have to use the arc height adjust system, while our height adjust system use the high sensor, one minute can send out 12,000 signal per minute, while other height adjust system usually send out 10000 signal per minute, so our cutting quality more better than other factory and cutting speed a litter faster than the same power plasma source.


    ③ we equipped the two fan for take the cutting smoke out from the room, front fan will blow to back, the back fan will exhaust the smoke out from the machine and out from the room. This way, will efficiency to let the workshop in the good environment. While other factory does not have this fan or only have one.


    ►Machine Data




    ModelHN-1530
    Working area (X-Y)1500mmx3000mm
    Working materialIron, Steel, Aluminum sheets, Galvanized sheets, Titanium Plates
    Working Thickness0.1-35 mm
    Cutting Speed0-6000mm/min
    Power8.5kw
    Input Voltage380V 50HZ (or according to your need)
    Plasma Current63A/100A/120A/160A/200A
    Connecting WayUSB
    Working ModeUntouched arc striking
    Cooling methodWith water pump and tank provide circulating water cooling
    Z axis travel0-70mm
    The automatic elastic raise0-5mm
    Rail guideTaiwan HIWIN linear square rails
    Transmit wayTaiwan imported ball screw
    Operation languageEnglish (Option)
    CommandG code, *uoo, *mmg, *plt
    Optional power sourceUSA brand Hypertherm
    Spare partsElectrode ,Electricity nozzle and Water jacket

    Product Advantage


    Cnc plasma cutting machine continues to provide wide and flexible solutions with its low investment and operation cost

    advantages, being appropriate to production lines and automation, improved accurate cutting quality.

    1. High Quality cut performance,Fast cutting speed,high precision and low cost.

    2. With firm and reasonable structure,the machine is easy to operate and durable for use.

    3. The cutting incision is thin and tidily and can avoid the second processing.

    4. High configuration CNC system, auto arc-striking and stable performance.

    5. Working with computer and support G code and files of Fast cam software.

    6. It can cut metal plate of advertising 3D lighting letter and flute profile letter with high cutting precision.(USA power is optional)


    Application


    The plasma cutting machine can be used to cut various metal materials such as stainless steel, aluminum, copper, cast iron, carbon steel, etc., not only the cutting speed is fast, the slit is narrow, the cut is flat, the heat affected zone is small, the deformation of the workpiece is low, the operation is simple, and it has significant The energy-saving effect. Plasma cutting machine is suitable for the manufacture, installation and maintenance of various machinery and metal structures, as well as cutting, opening, digging, and beveling of middle and thin plates.
