    High Power Speed Cnc Sheet Metal Double Table Fiber Laser Cutting Machine With Prot

    Ask Lasest Price
    Brand Name : Honest
    Model Number : HN-2060
    Certification : CE ISO
    Price : $25000 / Set-$50000 / Set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 20 Set / Month
    Delivery Time : After 8-20 Days
    • Product Details
    • Company Profile

    High Power Speed Cnc Sheet Metal Double Table Fiber Laser Cutting Machine With Prot

    Product Information:


    Fiber laser cutting machine laser as the light source is the use of fiber laser cutting machine, its superior performance, high speed, and high conversion rate, and many other advantages widely used in mechanical processing and machinery manufacturing industry, one of the most typical sheet metal cutting, cutting automobile industry and so on.


    Laser cutting, we can understand it for the separation of edge. Fiber laser cutting machine using optical fiber laser generator as a source of laser cutting machine. Fiber laser is the new development of a new type of fiber laser output laser beam of high energy density, and gathered in the work-piece surface, the work-pieces is super fine focus light irradiation area moment melting and gasification, move the light to shine through numerical control mechanical system and automatic cutting.

    High Power Speed Cnc Sheet Metal Double Table Fiber Laser Cutting Machine With Prot


    Product Data:


    Model
    3015
    4020
    6020
    Option
    Working area
    3000*1500mm
    4000*2000mm
    6000*2000mm
    According to demands
    Maxim running speed
    70m/min
    Laser wavelength
    1080 nm
    Minimum cutting line width
    0.1mm
    Rated output power
    1000W
    Repeated positioning accuracy of worktable
    ≤±0.015㎜
    Maximum load of worktable
    500KG
    Z axis travel
    120mm
    Machine power
    12KW
    Chiller
    2kw
    Power supply
    380v±10%
    Red light positioning
    provide
    X/Y axis positioning accuracy
    ±0.03mm
    X/Yaxis repeat positioning accuracy
    ±0.02mm
    X/Y axis repeat positioning accuracy
    140M/MIN
    Maximum acceleration
    0.6G-1.5G

    Product Applications:


    1. Sheet metal processing:Fiber laser cutting machine has the advantages of high precision, high speed, flexible processing (without mold opening), etc., and it has become a product of sheet metal processing. The high quality and high speed of fiber laser cutting machine are unique in the sheet metal industry and are favored by sheet metal companies.

    2. Automobile manufacturing:The automobile industry is a technology-intensive industry. Fiber laser cutting machine laser is a kind of cutting equipment. Now 50%~70% of auto parts are processed by laser. The automobile industry mainly uses laser welding and laser cutting as the main processing. Means, including plane cutting, three-dimensional cutting.
    3. Chassis cabinet:Manufacturers of computer cases, electrical switches, electrical cabinets, and elevators choose Pentium Laser's fiber laser cutting machine. What they value is the stability and high speed of the equipment. There is no need for secondary processing of the work-piece, which greatly increases production efficiency and reduces production costs.

    4. Advertising industry:The advertising industry is now more and more processing and cutting metal characters. Traditional metal characters have to go through a variety of processing techniques such as bending, welding, and polishing. Now, as long as the graphics are input into the computer, the fiber laser cutting machine can be used. Perform high-speed cutting.



    Certification:


    All products are available upon request, with or without trademarks.If you need OEM service with your own brand or product,please let us know,If you have any other specific requirements,please feel free to contact us. Our factory has obtained the import and export license issued by the Ministry of foreign trade,and passed the ISO9001 quality management system certification and CE certification.In the quality layer by layer,we will wholeheartedly serve for the majority of customers.
